TrailMaster
TRAILMASTER TM10 110CC DIRT BIKE, AUTOMATIC 4-STROKE
- SKU:
- TM10-DIRT-BIKE
- Note:
- LOCAL PICK UP CENTER
3201 E. Pioneer pkwy #34 76010 Arlington, TX, US - Shipping and Fuel surcharge Notice:
- About 99% of the customers will not get any shipping / Fuel surcharges, however only about 1% of the customers might get the surcharges on a case by case basis. Shipping to a very far away states and some rural area will incur extra shipping charges like NY, WA, SD, ND, MI, WA, CA, MT, OR, NV, ME, MA,PA, CT, DC, NH and the East Coast etc will be extra due to excessive fuel surcharges, and shipping to any islands will be extra. Please place your order normally if there are any extra shipping charges we will call you to inform you if not we will process your order as normal. We do not ship it to Hawaii and Alaska. Thank you for your understanding.
- Finance our Product (For Local Customers):
- If you are local to DFW please CLICK HERE to finance our product with
or Get Financing Options – Instantly. | PayPossible
TRAILMASTER TM10 110CC DIRT BIKE, AUTOMATIC 4-STROKE
- 110cc engine
- Kick start semi auto clutch
- 39.37 “ wheel base and 24.41” seat high
- Front tire 10”/Rear Tire 10”
- Hydraulic front and rear disc brakes
TECHNICAL Specs
Parts breakdown set up manuel
TM Dirt Bikes 10-11-15 | Parts |
- Engine Type 110CC, Single Cylinder, 4‐Stroke, Air Cooled
- Displacement 107 ml
- Automatic Clutch ,N‐1‐2‐3‐4
- Start Type Kick Start Only
- Bore x Stroke Ф52.4×49.5mm
- Max Power 6.7 hp
- Max Torque 7.5/5500±500
- Compression Ratio 9.0:1
- Min. Fuel Consumption: ≤367g/kw.h
- Engine Oil #: SJ5W一30
- Ignition CDI
- Transmission: #420 Chain, FT:14T/RR: 39T Sprocket
-
- Overall Size Length×Width×Height: (Inches)59.84X25.60X33.07 / (mm)1519X650X839
- Wheel Base 39.37"
- Seat Height 24.41"
- Ground Clearance 8.27"
- Fuel Capacity 2.2L / 0.58 Gal.
- Wheels Fr. & Rr. Both Steel 1.40×10/¢12 Rims, Cast Hubs
- Tire: Fr. & Rr. Both 2.50x10 ,Knobby tires
- Cradle Type Steel Tube Frame
- Front Fork ¢33*650mm Telescopic Forks, Non‐Adjustable
- Rear Shock ¢10*270mm , Non‐Adjustable
- Swing‐Arm Steel Tube 12inch
- Handle Bar Steel Crossbar ,L=620mm; Dia=¢22mm
- Front Brake Hydraulic Single Piston Caliper, 190mm Disc
- Rear Brake Hydraulic Single Piston Caliper, 190mm Disc
- Exhaust Black Pipe with catalyst converter(EPA Standard)
- Packing Size 49.4*13.2*24.2 inch
- N.W/LBS 111.3 LBS / 50 KG
- G.W/LBS 126.8 LBS / 58 KG
Product Dimensions
• Length×Width×Height: (Inches)49*13*24 / (mm)1244*330*609
• Weight : 127(Lbs) / 57(Kg)
